Dino completes the USSPA | profi commercial whirlpool spa series. In addition to Decree 238/2011 Coll., on public operations, it also complies with the German DIN 19643-1:2012-12 standard, thus fully meeting the most stringent criteria for public operations in Europe. Dino will perform well in the most demanding applications, such as aqua parks as well as hotels and other wellness centres. Where required, a thermal insulating cover may be additionally purchased for the whirlpool.
Technologies tailored to your operation. The sophisticated functions and very ingenious systems turn our spas into a highly safe, clean and pleasant relaxation spot. All the technologies are serviceable during the entire spa life, which lasts for decades. Rely on us.
The standard equipment of our spas is unusually broad. It contains absolutely everything you may need to use and operate our spas all year long. We also supply a number of interesting and attractive accessories to make your relaxation even more delightful.
Click below on the scale of colours and you will see your colour combination.
Download product details (pdf)
| Shell size | ø 256 × 100 cm |
|---|---|
| Frame size | ø 256 × 116 cm |
| Water volume | 1 630 l |
| Dry weight | 250 kg |
| Filled weight | 1 880 kg |
| MassiveShell Construction / color range | yes / 2 |
| Adjustable installation frame | yes |
| Total seating | 6-7 |
| Outflow - overflow channels | yes |
| Number of outfalls | 4 |
| Total number of jets | 44 |
|---|---|
| Water jets | 30 |
| Air Jets | 14 |
| USSPA iNtellismart® electropack | yes* |
|---|---|
| ISM® control system | yes* |
| Control keypad on electropack | yes* |
| Control via PC application (connection to local LAN needed) | yes* |
| Selfdiagnostic with optional protocol | yes* |
| Control of lifetime of selected components | yes* |
| iNcontrol piezo buttons | 3 |
| Pump 1 / single speed | 1,5 kW + 3 HP |
|---|---|
| Commercial air blower | yes |
| Sand filtration | yes* |
| Equalising tank | yes* |
| Automatic water level sensor | yes* |
| Automatic water refilling | yes* |
| UV lamp | yes* |
| Automatic chemistry dosing | yes* |
| Flowmeter | yes* |
| Heater | 9 kW Titanium Coil* |
| Light | yes |
| Handrail | 1 / stainless |
|---|---|
| Bottom outlet / sand filtration discharge | yes |
*This equipment is available only on selected markets. Ask your local dealer for more information.
